First published: 2017-02-08 / Updated: May 2026
2026 Note from DIY Dad: Kitchen Floor CF Finishing, IH Cooktop, and Built-in Dishwasher
ud83duded2 RECOMMENDED PRODUCTS
Modern Kitchen Cabinet Handles
New handles cost u00a53,000u20138,000 and make a kitchen feel 10 years newer instantly.
Once the floor repair is done, it’s time for the cushion floor (CF) finishing. Then comes the IH cooktop, followed by the big one u2014 the built-in dishwasher installation. Installing a dishwasher is one of the most advanced appliance DIY tasks out there.
Kitchen Floor CF (Cushion Floor) Finishing
ud83duded2 RECOMMENDED PRODUCTS
Kitchen Faucets
A faucet upgrade is the single highest-impact kitchen DIY per yen spent.
Kitchen CF laying requires many cut-outs u2014 for the drain, dishwasher opening, and cooktop area. The key is taking careful paper templates.
CF Laying Steps
- Make a paper template (using scrap CF or cardboard) to measure the floor shape
- For openings (drain, etc.): cut slightly small, then expand on-site
- Apply double-sided tape for flooring to the subfloor (full coverage is ideal)
- Position the CF and press down
- Roll out air pockets while pressing firmly
- Install baseboard and trim pieces to finish
Choose CF with water and oil resistance for kitchen use. Renovation-type CF has a thin backing and is easy to apply over existing flooring. m(_ _)m
IH Cooktop Installation
Switching from gas to IH requires closing the gas line and running a dedicated 200V power supply.
- IH cooktops require a dedicated 200V circuit (requires a licensed electrician)
- Gas line closure must be done by the gas company (never DIY)
- Confirm the existing cooktop opening matches the IH cooktop dimensions
- Confirm the countertop cut dimensions too
DIY Dad uses gas or IH depending on the property, since installing IH prevents tenants who can’t cook without gas from moving in.
Built-in Dishwasher Installation
ud83duded2 RECOMMENDED PRODUCTS
Kitchen Backsplash Tile Kits
A tiled backsplash protects the wall and dramatically upgrades the kitchen appearance.
This is the highest-difficulty kitchen DIY task u2014 involving cabinet opening, water supply, drainage, and power supply all at once.
Required Work
- Cabinet opening (create the space for the dishwasher)
- Water supply branch (branch connector from the stop valve)
- Drain connection (connect to sink drain trap)
- Dedicated power outlet (100V)
- Unit insertion and leveling
- Front panel fitting
- Test run (leak check)
Because there’s so much to do, breaking it into multiple sessions is smart. Be especially careful with supply and drain connections u2014 a leak will reach under the floor. m(_ _)m
Cabinet Opening Work
Creating the dishwasher space in an existing cabinet means removing drawers and shelves and widening the opening. DIY Dad cut part of the cabinet with a circular saw to secure the space.
Finish the cut edges with a router or sandpaper, then apply edge tape. Even hidden areas deserve a tidy finish u2014 future-you will thank you when doing maintenance.
Hi, it’s DIY Dad! No leak since yesterday u2014 what a relief! Continuing the 1F kitchen renovation u2014 time to select the built-in dishwasher.
A built-in dishwasher is structurally just a dishwasher contained within the kitchen cabinet. If we can carve out the space and figure out how to fix it in place, that’s all it takes.
So u2014 how much space do we need? Looking at manufacturer catalogs, the required space varies by model. Japanese manufacturers are fairly consistent with each other. On the foreign side, the most famous name is Miele u2014 a German manufacturer.
Miele u2014 the synonym for imported dishwashers.
A Miele dishwasher. The marketing copy says “powerful cleaning performance inspired by European food culture” u2014 DIY Dad is intrigued by that “powerful cleaning.” European food means lots of cheese, right? Can it really tackle baked-on hardened cheese? Want to try it! That’s all for today!
