2026 Note from DIY Dad: Structural Design Overview
ud83duded2 RECOMMENDED PRODUCTS
Pressure-Treated Deck Lumber
Pressure-treated lumber is the baseline u2014 skip it and you’ll be rebuilding in 5 years.
Once the materials were chosen, the next step is structural design — deciding what structure to build, how to detail the roof, what to do about the railing, working it all out by drawing plans.
Basic Structure of a Wood Deck
ud83duded2 RECOMMENDED PRODUCTS
Deck Stains & Waterproof Sealers
Stain every 2u20133 years. It’s the single cheapest way to double deck lifespan.
A wood deck is built in layers: footing (束石) → post (束柱) → beam (大引き) → floor joist (根太) → decking board.
- Footing (束石 tsuka-ishi): placed on the ground as a foundation — concrete block or pre-cast footing
- Post (束柱 tsuka-bashira): stands on the footing
- Beam (大引き ŏ-biki): laid across the posts along the long axis
- Floor joist (根太 neda): laid across the beams along the short axis, supporting the decking
- Decking board: surface material nailed onto the joists
How to Work Through the Structural Design
- Measure the installation space precisely (width, depth, floor height)
- Decide the deck surface height (align with the sash door threshold)
- Lay out footing positions (target span 900–1200 mm)
- Calculate beam and joist sizes and counts
- Calculate the number of decking boards and gaps (3–5 mm gaps)
- Create the materials list and get a cost estimate
If the span between supports is too wide the decking boards will deflect. Choose the right span based on board thickness and species.
Roof Detail Design
ud83duded2 RECOMMENDED PRODUCTS
Deck Screws & Fasteners
Use stainless screws only u2014 standard screws rust and stain the deck within one rainy season.
When adding a roof to a wood deck, the interface with the building is the biggest design challenge.
- Fix to building exterior wall — most common and robust
- Free-standing structure — no attachment to the building
- Extend existing eave or overhang
For a rental property, drilling into the exterior wall requires later patching. I chose a free-standing structure to allow full restoration.
Railing and Fence Design
When the deck is 30 cm or more above ground, consider installing a railing for safety. I planned a fence-style railing serving both as privacy screening and safety, using the same decking board material for a consistent look.
Originally published: 2017-05-30. It turned out that corrugated roofing and Super Light 700 are a poor match. Super Light 700 is too strong — to restore structural balance the roof substrate needed a weaker material. The conventional substrate for corrugated roofing is wood. SPF works well as a purlin (母屋) material while providing a softer substrate that accepts the corrugated roofing fasteners. The connection between polycarbonate corrugated roofing and SPF uses dedicated roofing nails — stainless steel screw nails:
↑ Stainless steel screw nails
These cost far less than the pipe bolt set option. A pack of 90 nails (9 rows × 10 strips) is ¥980. For the full roof area: 450/90 × 980 = ¥4,900. That works!
With this, all materials were finalized:
- Decking material: SPF
- Structural frame: Super Light 700 steel pipe
- Roofing: polycarbonate corrugated roofing
- Roof purlin (母屋): SPF
